Kegellager Timken 55434, Buitendiameter: 109.985 mm | Binnendiameter: 50.8 mm | Breedte: 19.726 mm
Kegellager
Zie technische informatieReferenties
Timken:55434
Rubix:03323641
EAN:0053893335070
Technische samenvatting
| Binnendiameter | 50,8 mm |
|---|---|
| Buitendiameter | 109,985 mm |
| Breedte | 19,726 mm |
Productdetails : TIMKEN 55434 CUP
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken 55434 cup voor TS-kegelrollenlager. Bore (cone-pair) 50,8 mm, buitendiameter 109,985 mm en cupbreedte 19,726 mm. Statische C0r 119000 N; dynamische Cr 126000 N.
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 19,726x109,985x109,985 mm |
| Logistiek gewicht | 474 g |
| Afmeting verpakking (D x B x H) | 31,75x117,602x117,602 mm |
| Binnendiameter | 50,8 mm |
| Buitendiameter | 109,985 mm |
| Breedte | 19,726 mm |
| Type lagerspeling | cn |
| Gewicht | 1,2 kg |
| Serie | 55000 |
| Koker | staal |
| Totale breedte lager | 29,251 mm |
| Statische basisbelasting, radiaal - C0r | 119000 N |
| Dynamische basisbelasting, radiaal - Cr | 126000 N |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 648,69 excl. BTW
/ stuk
€ 784,91 incl. BTW
- Levering doorgaans binnen 9 dagen
