Kegellager Timken H913840/H913810, Buitendiameter: 146.05 mm | Binnendiameter: 59.987 mm | Breedte: 25.4 mm
Kegellager
Zie technische informatieReferenties
Timken:H913840/H913810
Rubix:03326024
EAN:0053893004495
Technische samenvatting
| Binnendiameter | 59,987 mm |
|---|---|
| Buitendiameter | 146,05 mm |
| Breedte | 25,4 mm |
Productdetails : TIMKEN H 913840/H 913810 KEGELLAGER EENRIJIG
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. Timken patented the first in 1898 and today offers the world's widest variety in inch and metric sizes. This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the inner race assembly and the outer race. It is typically mounted in opposing pairs on a shaft.
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
This cup (outer ring) will need to be purchased with a matching cone (inner ring/cage/rollers).
Timken eenrijig kegellager H913840/H913810 (TS) met boring 59,987 mm en buitendiameter 146,05 mm. Radiale draagvermogens tot 256000 N (statisch).
Sterke punten
Single cone. One-piece pressed steel cage retains rollers on the cone and spaces them evenly. Pin type cages also available.
Toepassingen
Vehicle front wheels; Differential and pinion configurations; Conveyor rolls; Machine tool spindles; Trailer wheels
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistiek gewicht | 880 g |
| Afmeting verpakking (D x B x H) | 39,116x154,432x154,432 mm |
| Binnendiameter | 59,987 mm |
| Buitendiameter | 146,05 mm |
| Breedte | 25,4 mm |
| Type lagerspeling | cn |
| Gewicht | 3,2 kg |
| Serie | h913800 |
| Koker | staal |
| Totale breedte lager | 41,275 mm |
| Statische basisbelasting, radiaal - C0r | 256000 N |
| Dynamische basisbelasting, radiaal - Cr | 273000 N |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 704,41 excl. BTW
/ stuk
€ 852,34 incl. BTW
- Levering doorgaans binnen 9 dagen
