Kegellager Timken L433710D, Buitendiameter: 215.9 mm | Binnendiameter: 165.1 mm | Breedte: 47.625 mm
Kegellager
Zie technische informatieReferenties
Timken:L433710D
Rubix:03327845
EAN:0053893616889
Technische samenvatting
| Binnendiameter | 165,1 mm |
|---|---|
| Buitendiameter | 215,9 mm |
| Breedte | 47,625 mm |
Productdetails : TIMKEN L 433710 D CUP
The configuration of the TDO provides a wide effective bearing spread, making it ideal for applications in which overturning moments are a significant load component. TDO bearings can be used in fixed positions or allowed to float in the housing bore.
Timken l 433710 d cup
Sterke punten
Double cup and two single cones, with or without a spacer. When spacers are used, bearing is furnished as a preset, matched assembly. Cup features groove and lubrication holes in the OD. Spacers available with or without lubricant grooves and holes.
Toepassingen
Heavy-duty gear drives; Various industrial configurations
Technische informatie
Attributen
| Verpakkingshoeveelheid | 1 |
|---|---|
| Logistieke afmetingen (D x B x H) | 47,752x215,9x215,9 mm |
| Logistiek gewicht | 1715 g |
| Afmeting verpakking (D x B x H) | 58,7756x219,1512x219,1512 mm |
| Binnendiameter | 165,1 mm |
| Buitendiameter | 215,9 mm |
| Breedte | 47,625 mm |
| Type lagerspeling | cn |
| Gewicht | 1,71 kg |
| Serie | l433700 |
| Totale breedte lager | 58,74 mm |
| Aangepaste tariefcode | 84822000 |
Laten zien UNSPSC / ECL@SS / HS-codes
€ 4.005,15 excl. BTW
/ stuk
€ 4.846,23 incl. BTW
- Levering doorgaans binnen 9 dagen
